Gantry Type CNC Plasma Cutting Machine

Price 1700000 INR/ Unit

Get a Price/Quote

Gantry Type CNC Plasma Cutting Machine Specification

Type
CNC Plasma Cutting Machine

Material
Mild steel

Automatic Grade
Automatic

Control System
Frequency Speed Control

Cutting Function
Semi Automatic

Cooling System
Air Cooling

Drive Type
Electric

Warranty
5 Year

Gantry Type CNC Plasma Cutting Machine Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
15 Units Per Month

Delivery Time
2 Months

Main Domestic Market
All India

About Gantry Type CNC Plasma Cutting Machine

Features:

Heavy-Duty Gantry-Type Structure
Dual-shaft linear motion guide equipped with a rack and pinion drive system for precise transverse movement of the torch station.
Integrated anti-collision system featuring proximity sensors for enhanced protection.
Electrical limit switches installed at both ends of the longitudinal track, complemented by mechanical bumpers to provide emergency collision protection.
High-tension, high-accuracy dual-rail rack and pinion drive for smooth longitudinal movement.
Automatic wear compensation mechanism utilizing high-tension cup springs ensures continuous, backlash-free engagement between the pinion and rack.
Electrical limit switches positioned at both ends of the transverse track and torch suspension, combined with mechanical bumpers, deliver additional emergency collision protection.
Track wiper device for maintaining track cleanliness and optimal performance.

APPLICATION:

Pre Engineering Building (Peb)
Heavy Fabrication
Chemical Plant Machinery Mfg
Tank Mfg
Tower Mfg
Job Work
Road Machinery Equipments Mfg
Food Processing Machinery Mfg
Metirial Handling Equipments
Hydraulic Machinery Mfg
Agriculture Machinery Mfg

Technical Specifications

Model	ADK 2508 P/F	ADK 3508 P/F	ADK 4008 P/F	ADK 5508 P/F
Working Width (mm)	1800 x 6500	2800 x 6500	3200 x 6500	4500 x 6500
Speed (mm/min)	0-12000
Accuracy (mm/3mtr)	+0.03
Power Source Capacity (amp)	PMX 45, PMX 65, PMX 85, PMX 105 , PMX 125 , MAXPRO 200
Source Make	Hypertherm

The Gantry Type CNC Plasma Cutting Machine combines precision, durability, and efficiency. It is crafted from robust mild steel, ensuring long-lasting performance in demanding industrial environments. Equipped with an electric drive, this machine guarantees reliable operations, allowing smooth and accurate cutting. Designed with a semi-automatic cutting function and frequency speed control system, it ensures optimal cutting precision for various applications. This fully automatic machine boasts an advanced air cooling system, which minimizes overheating and enhances operational efficiency. With a comprehensive 5-year warranty, the Gantry Type CNC Plasma Cutting Machine offers peace of mind for manufacturers and suppliers looking for reliable equipment. Perfect for high-performance requirements, it delivers consistent results suitable for numerous cutting applications.

Automation Grade	Fully-automatic
Power	2 kVA
Voltage	AC 220 V
Max Cutting Thickness	30 mm
Max Cutting Speed	1000 mm/min
Phase	Single Phase
Max Cutting Width	3000 mm
Machine Power	AC 220 V (Single Phase) (+/-10%), 50 Hz, 2 KVA
Brand	ADK
Plasma cutting	Depend on power Source
Plasma Power	As per Power Source
Frequency	50 Hz
